GP4000 Series Hardware Manual
129
Dimensions
NOTE:
z If you are using the rear mount model, refer to Dimensions (see page 184).
External Dimensions
1 Front
2 Right Side
3 Top
301
11. 85
315
12.40
56
2.20
5
0.20
241
9.49
227
8.94
mm
in.
(1)
(3)
(2)
(GP-4601T)
