#10 x 3/4" Screw
(8)–4
#8 x 3/4" Screw
(4)–10
3/8" x 3 1/4" Screw (2)–6
5/16" x 3" Screw (7)–2
3/8" Star
Washer (3)–6
5/16" x 3/4"
Screw (5)–2
#10 Star
Washer (23)–4
5/16" Star
Washer (6)–4
#8 x 1/2
" Ground
Screw (1)—1
1/4" x 1 3/4"
Screw (77)–2
#8 x 1/2" Machine
Screw (91)–4
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity used for assembly.
