M10 Locknut
(81)–2
M8 Jam Nut
(79)–7
M4 x 16mm Round
Head Screw
(101)–6
M8 x 69mm Bolt (80)–1
M10 x 80mm Carriage Bolt (82)–2
Hub Screw (87)–8
M8 x 23mm Screw
(84)–4
M8 x 41mm Bolt
(78)–4
M8 x 80mm Bolt (116)–2
M10 x 127mm Screw (83)–2
M4 x 32mm Round
Head Screw (105)–6
#10 x 51mm Screw
(108)–4
M8 Washer
(88)–6
Wave Washer
(111)–2
M8 Split
Washer
(90)–3
#10 Washer
(102)–8
M4 x 16mm Screw
(103)–6
#8 x 16mm Screw
(112)–4
#10 x 13mm Screw
(104)–4
M8 x 23mm Shoulder
Screw (115)–4
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
