Pro-Form PFEVEL30618.1 User Manual

5
M8 x 77mm Bolt (79)–2
M10 x 20mm
Screw (40)–6
M6 Bolt Set (25)–2
M8 x 41mm Bolt (50)–6
M10 x 68mm Screw (34)–4
M10 Locknut
(33)–1
M8 Jam Nut
(38)–8
M8 x 10mm
Screw (27)–6
M8 x 25mm
Screw (56)–2
M4 x 16mm
Screw (52)–8
M10 x 28mm
Washer (83)–2
M8 Washer
(55)–2
M10 Curved
Washer (32)–1
M10 x 77mm Bolt (7)–1
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled.

Pro-Form PFEVEL30618.1 Specifications

General

Brand	Pro-Form
Model	PFEVEL30618.1
Category	Elliptical Trainer
Language	English
