14. Attach the Weight Top Frame (66) to the Press Top
Frame (9) with two 5/16Ó x 2 3/4Ó Bolts (89), a
Support Plate (94), and two 5/16Ó Nylon Locknuts
(64). Do not tighten the Nylon Locknuts yet.
Attach the Weight Top Frame (66) to the bracket on
the Press Upright (2) with two 3/8Ó x 2 3/4Ó Bolts (46),
two 3/8Ó Flat Washers (48), and two 3/8Ó Nylon
Locknuts (50). Do not tighten the Nylon Locknuts
yet.
14
66
89
50
64
9
64
48
94
2
46
13. Attach the Bumper (40) to the indicated hole in the
Press Front Leg (20) with a 1Ó Tap Screw (80).
Press two 2Ó Square Inner Caps (28) into both ends
of the Leg Lever (41). Lubricate the 3/8Ó x 3 1/4Ó Bolt
(62). Attach the Leg Lever (41) to the Press Front Leg
(20) with the Bolt and a 3/8Ó Nylon Jam Nut (63). Do
not overtighten the Nylon Jam Nut; the Leg Lever
must pivot freely.
62
Lubricate
41
20
6
63
28
28
80
40
13
12. Attach the Press Seat Frame (7) to the Press Upright
(2) with two 5/16Ó x 2 3/4Ó Bolts (89), two 5/16Ó
Washers (36), and two 5/16Ó Nylon Locknuts (64). Do
not tighten the Nylon Locknuts yet.
Press a 2Ó Square Inner Cap (28) into the top of the
Press Front Leg (20).
Slide the bracket on the Press Front Leg (20) onto
the indicated 5/16Ó x 2 1/2Ó Carriage Bolts (92) in the
Press Base (6). Hand tighten two 5/16Ó Nylon
Locknuts (64) onto the Bolts. Do not tighten the
Nylon Locknuts yet.
Attach the Press Seat Frame (7) to the Press Front
Leg (2) with two 5/16Ó x 2 3/4Ó Bolts (89), two 5/16Ó
Washers (36), and two 5/16Ó Nylon Locknuts (64). Do
not tighten the Nylon Locknuts yet.
89
36
36
64
20
7
28
89
64
6
2
92
64
89
64
36
12
15
15. Attach each Weight Guide (15) to the Weight Top
Frame (66) with a 3/8Ó x 3 3/4Ó Bolt (59), a 3/8Ó Flat
Washer (48), and a 3/8Ó Nylon Locknut (50).
Important: Go back and fully tighten all Nylon
Locknuts used in steps 1 through 15.
59
48
66
15
50
