Pro-Ject Audio Systems Phono Box RS - Input Configuration and Gain Settings; Input Gain and Connector Selection; Variable Input Impedance (Low-Output MC); Variable Input Capacitance (MC;MM)

© Audio Trade GmbH · Pro-Ject Phono Box RS · Revision 2012.9.1
3
Input / output connectors, input gain
RCA / XLR select the connectors to be used. Input gain for RCA can be set to 60, 50 or 40dB. The possible
settings for XLR are 66, 56 and 46dB.
RCA
XLR
60
66
50
40
56
46
Input impedance, variable – low-output MC cartridges
* Input capacitance is irrelevant for low-output MC cartridges
The switch F/ V must be set to V
1200
1100
1000
700
400
200
150
130
100
60
30
20
10
Ohm
Input capacitance, variable – high-output MC and MM cartridges
The switch F/ V must be set to F
ON
200pF
300pF
420pF
520pF
100pF
100pF
220pF
10R
47k
Fixed
23
4
2
1
ON
23
4
2
1
ON
23
4
2
1
ON
23
4
2
1
ON
23
4
2
1
ON
100pF
23
4
2
1
Input impedance, fixed – low-output MC cartridges
* Input capacitance is irrelevant for low-output MC cartridges
The switch F/ V must be set to F
10 Ohm
100pF
100pF
220pF
10R
47k
Fixed
ON
23
4
2
1
ON
23
4
2
1
To find out which type your cartridge is, please consult the literature accompanying your cartridge.
The literature for cartridges should also specify the correct input impedance (low-output MC
cartridges) and the correct input capacitance (high-output MC and MM cartridges), into which the
cartridge is designed to work. If in doubt please consult your dealer.
