pro.point 200A - Assembly and Installation

8612517 200A SPOOL GUN KIT V1.0
Remove the parts and accessories from the packaging and inspect
for damage. Make sure that all items in the parts list are included.
Contents:
• Spool Gun with assembled Contact Tip, Torch Nozzle, Gas
Diffuser and Insulator.
ASSEMBLY & INSTALLATION
When this manual refers to a part number, it refers to the
included Parts Identification section.
1. Select the spool gun using the Standard/Spool Gun
selector switch inside the welding machine’s side panel
(Fig. 1-2).
1-1
1-2
1-3
1-4
1-5
1-6
1-7
Fig. 1
4 For technical questions call 1-800-665-8685
