pro.point 8913204 - Gas Engine

V1.0 8913204
Please read and understand all instructions before use. Retain this manual for future reference.
SPECIFICATIONS
Engine Displacement
420cc
Theoretical Horsepower
15 HP
Start Type
Pull/12V DC
Torque
19.54 ft-lb
Shaft Diameter
1 in.
Shaft Rotation (From PTO Shaft Side)
Counterclockwise
Shaft End Tapped
[Diameter (in) / Threads Per Inch]
3/8 -24 UNF
Number of Cylinders
1
Cylinder Bore
90 mm
Stroke
66 mm
Compression Ratio
8.8:1
Cooling System
Air
Fuel Tank
Metal
Fuel Type
Gasoline (87+ Octane)
Fuel Tank Capacity
5.8 quarts (5.4 litres)
Fuel Filter
Yes
Oil Capacity
1.16 quarts (1.09 litre )
Lubrication System
Splash
Oil API Service Classification
SF or Newer
Low Oil Shutdown
Yes
Governor System
Mechanical
Ignition System
Transistorized Magneto
Max. Speed 3,600 RPM
Spark Plug (Torch F7TC)
Gap
0.027~0.031 in. (0.7~0.8 mm)
Torque
18~22 Nm
Air Cleaner Type
Foam
GAS ENGINE

FOR PRESSURE WASHER (8913204)
