# DESCRIPTION QTY
13 Release Valve 1
14 Pump 1
15 Long hydraulic hose 1
16 Oil Filler Plug 1
17 Bolt M10x15 4
18 Lower round nut 1
19 Cylinder base plate 1
20 Bolt M8x65 4
21 Pressure gauge 1
22 90° connection nut 1
23 Three-way valve block 1
24 O-Ring 1
25 Pressure gauge connector 1
26 Nut 1
27 90° connection nut 1
28 Spring 4
29 Fixing plate 2
30 Upper round nut 1
31 Cylinder ram 1
32 Short hydraulic hose 1
# DESCRIPTION QTY
33 Bolt M10x20 1
34 Bed frame 1
35 Heel block 2
36 Bed frame pin 2
37 Clip 2
A1 Screen handle 1
A2 Washer M6 2
A3 Nut M6 2
A4 Bolt M6x20 2
A5 Protective screen 2
A6 Bolt M10x50 4
A7 Washer M10 12
A8 Adjusting base, left 1
A9 Long bushing 4
A10 Knob 2
A11 Bolt M10x35 4
A12 Roller bushing 4
A13 Short bushing 4
A14 Adjusting base, right 1
V1.0 PNEUMATIC/HYDRAULIC SHOP PRESS 9081548
Page 21 Assistance available at www.princessauto.com or 1-800-665-8685
