pro.point 9081548 - Parts Breakdown; Parts List

PARTS BREAKDOWN
PARTS LIST
#
DESCRIPTION QTY
1 Frame 1
2 Bolt M10x30 12
3 Support strut 4
4 Base 2
5 Washer M10 17
6 Lock washer M10 12
# DESCRIPTION QTY
7 M10 Nut 12
8 Foot air valve 1
9 Intake air hose 1
10 Air hose 1
11 Handle 1
12 Air pump 1
9081548 PNEUMATIC/HYDRAULIC SHOP PRESS V1.0
Assistance available at www.princessauto.com or 1-800-665-8685 Page 20
