4
4. Hold button
When this button is pushed, the display will keep the last reading
and " " symbol will appear on the LCD until pushing it again.
5. "10A" jack
Plug in connector for red test lead for 10A measurement. "COM"
jack
6. Plug in connector for black (negative) test lead. "VmA" jack
7. Plug in connector for red (positive) test lead for voltage,
resistance and current (except 10A) measurements.
SPECIFICATIONS
Accuracy is specified for a period of one year after calibration and at
18°C to 28°C(64°F to 82°F) with relative humidity to 80%.
GENERAL
Maximum voltage between
terminals and earth ground
Fuse protection
Power
Display
Measuring method
Overrange Indication
Polarity indication
Operating environment
Storage temperature
Low battery indication
Size
Weight
