19
⚫ Protection of protective tube: mA position: protective tube F 500mA/250V;
A position protective tube F 10A/250V
⚫ Rotation rate: approximately 3 revolutions/second
⚫ Display unit: 6000 counts displayed on LCD screen. Automatically display
the symbol for unit in accordance with measurement function position. ⚫
Outrange indication: the LCD screen will display "OL".
⚫ Battery Low indication: “ ” will appear when the battery's voltage is
below the normal working voltage.
⚫ Input polarity indication: “ ” will automatically appear.
⚫ Power: 1 x 9V 6F22 battery
⚫ Dimensions: 190 mm(L)×89mm(W)×53mm(H).
⚫ Weight: approximately 315g (not included batteries or test leads)
4.2 Precision indicator
Accuracy: ( reading + digit)
The accuracy warranty will run for 1 year upon the ex-factory date.
Reference conditions: Ambient temperature is between 18℃ and 28℃ and
relative humidity is no more than 80 .
4.2.1 DC voltage
