2
Test
Functions
Range
Accuracy
Remarks
DCV
0-0.1-2.5-10-50-
250V -1000V
 3% FSD.
 4% FSD.
For 1000V
Input Impendence:
20KΩ/V
Overload Protection:
Max. 1000V AC/DC
BUT at 0.1/2.5/10V,,
250V Max.
ACV
0-10-50-250V
-1000V
 4% FSD.
 5% FSD.
for 1000V
Input Impendence:
9KΩ/V
Overload Protection:
Max. 1000V AC/DC But
10V/50V only 250V
Max. Band width: 40
~10K Hz
DC mA
0-0.05-2.5-25-
250 mA,
 3% FSD.
Drop Voltage: 250mV
Overload protected by
Fuses 0.5A/250V, and
Oxide Varactor. <250V
AC/DC(5s).
Ω
X1: 0.2 ~ 2KΩ
midscale at 20Ω
X10: 2~20KΩ
Midscale at 200Ω
X100:20~200KΩ
Midscale at
2000Ω
X1K: 200~ 2MΩ
Midscale at 20KΩ
X10K: 2K ~
20MΩ Midscale
at 200KΩ
 4% of ARC
of Scale
Length
Overload protected by
the Oxide Varactor &
Fuse <250V AC/DC(5s).
Capacitance
(uF)
2000uF
Approximate
Value
Use the Ω X 1K range
BATT Check
0 ~ 1.5V: GOOD
- ? – BAD
0 ~ 9V: GOOD - ?
– BAD
 5% of ARC
of Scale
Length
Load Current:
270mA for 1.5V, 25mA
for 9V.
Overload protected by
Fuse & Oxide Varactor
<250V AC/DC(5s).
Continuity
Check
Beeper sounding
under 200 Ohm
Overload protected by
Fuse & voltage
Suppressor <250V
AC/DC(5s).
