3
Transistor
Check
hFE: 0-1000 via
special hFE
socket
Approximate
Value
At Ω X 10 Range
LED, Diode
Check
via special hFE
socket
Approximate
Value
At Ω X 10 Range
Decibel
-22 dB ~ + 62 dB
(0dB=1mW at
600Ω)
Approximate
Value
At ACV ranges
Power
Source
Internal Battery: R03, AAA, 1.5V 2pcs, 6F22, NEDA1604, 9V
1pc
CALIBRATION
Ω Zero Adjustor located at the right side of the panel, adjusting the meter
pointer to the Zero mark on the right side of Ω scale of the meter dial when
the test leads are touched together.
Mechanical Adjustor Screw: located right below the center of the meter dial
to set pointer to Zero mark at the left side of the scale.
(-) Jack: Plug-in connector at the lower left on the panel for Black, negative
test lead.
(+) Jack: Plug-in connector at the lower right on the panel for Red, positive
test lead.
