7
OPERATION
Locating and Isolating Cables：
Using MT-7029 to locate and insolate cables using the 130KHz
analog, also trace twisted wires (UTP, STP, Cat 5, Cat 5e, Cat 6)
and telephone line(Cat 3). Use with a patch cord for RJ45 / RJ11
coaxial cable, general cable and various wiring boards can be tested
by using with alligator clip cable.
Warning
• It is not intended to be used on live wires with a DC power
source over DC 48V (e.g., live telephone lines), nor will it work
on wire pairs that are carrying AC signals.
• Use RJ45 SCAN compatible connector for RJ45 cable tracing.
Use RJ11(6 pin) connector for RJ11(6P/6C/4C/2C) cable tracing.
Use RJ11 (6 pin) connector and work with alligator clips for
coaxial cable, general cable and various wiring boards.
Caution
• The position on the MT-7029 lets you use the Receiver to trace
using an analog 130KHz tone. When using the Receiver to
isolate the tone source in the cable bundle or at the patch panel,
the signal might be interfered with or decreased and the signal
will not pass through metal tubes.
• It is not necessary to touch the Receiver’s tip to the cable or
patch panel when searching for the Transmitter’s signal.
• Make sure the black alligator clip of the Transmitter is connected
to the ground before use.
• When using the MT-7029 with earphone to locate and isolate
cables, please keep probe away from the earphone to avoid
interference of resonance effects
• When doing cable locating, if the signal becomes intermittent,
trailed off or interrupted, the receiver may be disturbed by the
harmonics of other devices. Please move your position for better
signal.
• Different PoE injector may cause Receiver signal to be
intermittent, trailed off or interrupted; please move your position
for better signal.
• When doing PoE scan, bigger current consumption, which will
