Volume Measurement
Press
twice, the symbol appears in the
function field on the display. Press to take the first
length measurement (e.g. Length). Next get the width,
then height, the result of length, width, height and volume
is displayed in order.
Indirect Measurement - Pythagorean
Instrument calculates indirect distance using
Pythagorean Theorem. Note: Target points should be in
the same line. When measuring the 2nd distance, laser
beam should be right-angled to the line.
Pythagorean Two Points
Refer to figure 1. Press
to activate the function, the
symbol appears in the function field on the display.
Take No. 1, and No. 2 length, the result is displayed on
the summary line. Press
to delete any measured
length and then press to re-measure.
6
