MOUNTING OF THE BIKE CARRIER ONTO THE TOWBAR
When mounting the bike carrier to the car, it is best that the car is parked
straight, the engine is turned off and the parking brake is activated. Make sure
that the towbar is undamaged, clean and not greasy!
The bike carrier can be mounted with the coupler on the
towbar of your car. Slightly tighten the big bolt (M16x90).
Check if the carrier runs parallel to you car (or bumper of
your car). Next, tightly screw the bolt down with the
supplied key until the carrier can no longer move on the
towbar.
If you wish you can protect your bike carrier against theft by
means of a lock. You can insert the lock into the socket.
TILTING MECHANISM
For easy access to the boot of your car, even if the bikes are mounted on the
carrier, you may use the tilting mechanism.
The bike carrier has two locking pins to
secure the tilting mechanism.To tilt the
carrier, you rotate the two locking pins by a
quarter turn so the handles are horizontal.
Subsequently you pull out the two pins. With
one hand, keep a firm grip on the frame or
the bikes, so that the carrier can not fall
down in an uncontrolled movement. It is now
possible to tilt the carrier.
To secure the carrier again, you have to lift it
and push the two locking pins back in.
Subsequently you rotate the pins again by a
quarter turn so the handles are vertical with
the long part downwards. You will hear a click
once they are secured.
Make sure that both locking pins are secured before you continue
driving!
Locking pins
