16
INSTALLING/REMOVING THE FRONT RIGGINGS
NOTE: This procedure applies to the
swing away footrest and the
elevating legrests front riggings
Installing
1. Turn the front rigging to the side (open footplate is perpendicular to wheelchair).
2. Install the front rigging hinge plates onto the hinge pins on the wheelchair frame.
3. Push the front rigging towards the inside of the wheelchair until it locks into place.
NOTE: The footplate will be on the inside of the wheelchair when locked in place.
4. Repeat STEPS 1-3 for the opposite side of the wheelchair.
5. To release the front rigging, push the footrest release lever inward, rotate footrest
outward.
Removing
1. Push the rigging release lever inward and rotate the front rigging outward.
2. Lift up on front rigging and remove from wheelchair.
3. Repeat STEPS 1-2 for the opposite side of the wheelchair.
