GENERATOR
Introduction
To get the most out of your new generator,
please read through these instructions and
the attached safety instructions before
use. We also recommend that you save the
instructions in case you need to refer to them
at a later date.
Technical data
Engine: 7 hp 208 cc 4-stroke
Starting system: recoil start
Fuel: 95 octane unleaded petrol
Engine oil: SAE10W-40
Outlet:
2 × 230 V~ 50 Hz 2600/3000 W
1 × 12 V DC 8.3 A
Tank capacity, petrol: 15 litres
Tank capacity, oil: 0.6 litres
Running time on full tank: 11 hours
Noise level: 95 dB(A)
Main components
1. Petrol tank
2. Fuel cap
3. Petrol gauge
4. Frame
5. 12 V socket
6. Reset button for 12 V socket
7. 230 V socket
8. Breaker for 230 V socket
9. Earth terminal
10. Voltmeter
11. Indicator light
12. Main switch
13. Oil bung
14. Oil drainage cap
15. Starter handle
16. Petrol cock
17. Air fi lter cover
18. Muffl er
19. Spark plug
20. Choke
21. Carburettor
