Programming the transmitter
Switching on the IEM7120 transmitter:
Hold the POWER button down for 3 seconds until your transmitter comes on.
Do the same to switch off.
Selecting the group and channel for your system:
Press the "SET" button (system setup) and the "Group" indicator will flash on the screen.
Press on the "▲" or "▼" button to select the number of the appropriate frequency group.
Press the "SET" button again and the "CHANNEL" indicator will flash on the screen. Press
on the "▲" or "▼" button to select the appropriate channel.
FOR INFORMATION: when you have several systems on the go, make sure that all your
systems are using the same frequency group and select a different channel number for
each system.
Selecting mono or stereo mode:
Hold down the "SET" button (system setup) until the "STEREO" indicator flashes. Press on
the "▲" or "▼" to select "STEREO" (L+R) or "MONO" (L+R), then press on the "SET"
button again to exit the menu.
FOR INFORMATION: In "STEREO" mode, if only one connector lead is connected to the
transmitter, the signal will automatically be transmitted in mono (L to R+L or R to R+L).
