Receiver functions and features
A. Front panel:
6. POWER button: turns on/turns off the receiver
7. RF Light: indicates RF signal and PEAK level
8. POWER/AF: power indicator.
9. SCAN & ACT Sync Button (marked A and B on the TT100 Duo UHF Lanen).
10. Diaphragm [IR].
B. Rear panel:
6. Power Jack (DC 12-18V).
7. Unbalanced 6.35mm mono audio output jack.
8. Balanced XLR audio output jack (marked A and B on the TT100 Duo UHF Lanen).
9. Volume Control (marked A and B on the TT100 Duo UHF Lanen).
10. MIX OUT mono audio output (A+B) Unbalanced 6.35mm jack (TT100 Duo UHF
Lanen).
Transmitter functions and features
7. Battery compartment LR6/AA (x2).
8. Receiver [IR] for automatic channel setting.
9. Power light.
10. Switch (ON | MUTE | OFF).
11. Setting the Gain Level: turn the control to the right to increase gain.
12. Mini XLR Socket for headphones or lapel mic (optional).
