II.6.5.1. USB Ports for Wi-Fi
A USB Wi-Fi modem can be supplied optionally with the unit. This Wi-Fi
connection can be used for streaming or for bonding to other IP interfaces to
stream audio and video data.
Wi-Fi standards: 802.11b, 802.11g, 802.11n
Security protocols: 128-bit WEP, 64-bit WEP, WPA, WPA2.
II.6.6 3G/4G Connector
This connector allows the user to plug the external Wireless Communications
Module. This module will provide the unit with up to four 3G/4G modems and
high gain antennas, to connect to mobile data networks. For more information
about the configuration and usage of the 3G/4G connections please refer to the
Quantum Family User Manual.
Supported technologies and frequencies:
LTE (FDD) B1/B2/B3/B4/B5/B7/B8/B20 (2100/1900/1800/850/2600/900/800)
DC-HSPA+ / HSPA+ / HSPA / UMTS dual-band B1 / B2 / B5 / B8 (2100 /
1900 / 850 / 900)
EDGE/ GPRS/ GSM quad-band 850/900/1800/1900 MHz
II.6.7 Antenna connector and SIM card slot
Quantum W offers the choice of including an internal 3G/4G modem. When this
option is chosen, an external antenna is provided and has to be plugged to its
correspondent connector for a correct wireless communication.
On the rear part of Quantum W there is a slot for the insertion of the 3G/4G
modem’s SIM card.
II.6.8 Power supply
Quantum W comes supplied with an AC/DC converter (19 volts output) to be
connected to the power connector located at the rear panel. The power
converter works with an AC input range of 100 to 240 VAC, 50 to 60 Hz.
