DSO26 2. Specifications
Data Sheet
Inputs 2 electronically balanced
Impedance > 10k Ω
CMRR > 65dB 50Hz - 10kHz
Outputs 6 electronically balanced
Source Imp < 60 Ω
Min. Load 600 Ω
Max. Level +20dBm into 600 Ω
Frequency Resp. ±0.5dB 20Hz-20kHz
Dynamic Range >110dB 20Hz-20k unweighted
Distorsion < .02%@1kHz,+18dBm
Max Delay 650 ms
Min Step Size 2.6 µs
Gain Inputs +6dB to -40dB in 0.1dB steps
Gain Outputs +15dB to -40dB in 0.1dB steps and mute
Parametric EQ 5 Sections per output
Gain +15dB to -30dB, 0.1dB steps
Freq. Range 20Hz - 20kHz, 1/36 octave steps. (368 positions)
FilterQ/BW 0.4-128 / 2.5-0.008
Shelving sections Low freq. 20Hz - 1kHz
High freq. 1kHz - 20kHz
Shelf gain ± 15dB in passi da 0.1dB
High and lowpass filters Filters 1 of each per output.
Freq. Range HPF 10Hz - 16kHz 1/36 octave steps.
Freq. Range LPF 35Hz - 22kHz 1/36 octave steps.
Responses Bessel/Butterworth 12-18-24dB/Oct.
Linkwitz-Riley 24dB/Oct.
Limiters 1 of each per output
Threshold +22dBu to -10dBu
Attack time 0.3 to 90 ms
Release time 2/4/8/16/32 x Attack time
Display 2x20 character backlit LCD
Input meter 2 x 3 point
Output meter 6 x 3 point
Connectors
Inputs 3 pin female XLR
Outputs 3 pin male XLR
External 9 pin DEE (RS232)
Power 3 pin IEC, 60 to 250V ± 15% @ 50/60Hz
Consumption < 20 watts
Weight 3.5kg. Net (4.8kg. Shipping)
Size 1.75”(1U) x 19” x 11.8”
(44 x 482 x 300mm) excluding connectors
