PROEL M-20 - Connection Example; System Connection Diagram

32
ENG ITA
CONNECTION EXAMPLE ESEMPIO DI CONNESSIONE
CONNECTION EXAMPLE
ESEMPIO DI CONNESSIONE
RIGHT
LEFT
MAIN MIX OUTPUT
BALANCED
USB PORT
VOICE
SAX
KEYBOARDS
HD OR DAT RECORDER
PROCESSOR
FOOTSWITCH
FOOTSWITCH
ELECTRIC GUITAR
BASS
DRUM KIT
ACOUSTIC GUITAR
DI-BOX
CHOIR
STUDIO AMPLIFIED
MONITOR SPEAKERS
AMPLIFIED
MONITORS
MAIN P.A.
AMPLIFIER
MAIN P.A.
PASSIVE SPEAKERS
31-BAND EQUALIZER
HEADPHONES
PIANO
P.C. WITH DAW SOFTWARE
(DIGITAL AUDIO WORKSTATION)
