TECHNICALSPECIFICATION
RM3000–UHFPLL8ChannelTransmitter
RFChannels 8frequencypreset
RFFrequencyBand UHF:863865MHz
RFPeakDeviation ±68KHz
RFOscillationMode PLLSynthesized
RFModulationType WidebandFMStereo
RFOutputPowerat50 L(low)<10mW/M(mid)<50mW/H(high)<100mW
RFSpuriousRejection 60dBc
RFAntennaConnector TNT(50Impedance)
FrequencyResponse 50Hz–15KHz(±3dB)
THDDistortion <0.5%
S/NRatio >90dBA
DynamicRange >105dB
AudioInput 2xXLRF/JACKBalanced
AudioOutput 2xXLRMBalanced
InputLevelNominal 0dBu(775mV
rms
)
InputLevelMax +8dBu(2V
rms
)
PowerSupply 1315VDC/500mA
Dimensions(WxDxH) 205x185x51mm
Weight 0.80Kg

RM3000R–BodypackEarphoneUHFPLL8ChannelsReceiver
RFChannels 8frequencypreset
RFFrequencyBand UHF:863865MHz
RFPeakDeviation ±68KHz
RFOscillationMode PLLSynthesized
RFModulationType WidebandFMStereo
RFFrequencyStability ±0.005%(10÷+50°c)
RFReceivingSensitivity <107dBm
RFSquelchlevel 90dBm
THDDistortion <1%
S/NRatio >94dBA
ChannelSeparation >42dB
FrequencyResponse 80Hz–15KHz(±3dB)
AudioOutput 3.5mmStereoHeadphoneFemaleMiniJack
OutputPowerMax(continuous) 2x50mW
OutputPeakPower(withLimiter) 2x14mW
HeadphoneImpedance >16ohm
Limiter 10dBorswitchedoff
PowerSupply 2x1.5VAAAlkalineBattery
PowerConsumption 150mA
OperatingTime 4to8hrs(dependingofvolumelevel)
Dimensions(WxDxH) 65x28x107mm
Weight 0.12Kg
