7. ROUTPUT(XLRoutputBALANCED)
SameasabovefortheRINPUT.
8. POWER
ON/OFFswitch:theLEDshowstheONorOFFstatusofthetransmitter.
9. PHONES
Auxiliaryheadphonesoutput.
10. PHONESVOLUME
Volumepotentiometerfortheauxiliaryheadphonesoutput.
11. MONO/STEREO
ThisswitchcombinestheL&RinputstogetherandsendstheresultingmonosignaltobothL&R
earphoneschannels.Incaseofasinglechannelinput(LorR)thisswitchmustbepressedinorderto
sendthesamesignaltobothL&Rearphoneschannels.
12. LINPUTMETER
5LEDbarmeterofLchannelshowingtheinputlevel.ThelastREDLEDlightupjustabovethenominal
inputsignal(+5dBu):forgettingtheoptimalRFtransmissiondynamicrange,reducethelevelofinput
signaliftheredLEDlights.
13. RINPUTMETER
SameasabovefortheRinputchannel.
NOTE:thebarLEDshowsthesignaljustbeforetheRFtransmitterchannels,soaftertheMONO/STEREO
andthe+10dB/0dBswitches.
14. +10/0dBGAIN
Whenengagedthisswitchenhancestheinputsignalof10dB:useitincaseoflowlevelinputsignals.
15. CHANNELSELECT
Theseswitchesareusedforselectingthetransmissionchannel:pressandholdtheUPorDOWNswitch
untilthedisplayflashes,thenpressagaintheUPorDOWNswitchtoscrollthechannels.After6seconds,
ifnooneswitchispressed,thedisplaylightssteadyandthetransmissionstartsontheselectedchannel.
16. CHANNELDISPLAY
The2digitdisplayshowstheselectedchannel.
RM3000RBODYPACKRECEIVER
17. ANTENNA
Thisisthereceivingantenna.Itisshortandflexibleforthemaximumusercomfort:donotforceit.
18. EARPHONESVOLUME
Thiscontrolsetstheearphonesoutputlevel.Wesuggesttosetacomfortablebutnotexcessivelevel,in
ordertoavoidtostressordamageyourears.Readthesafetynotesatthebeginningofthismanual.
19. TONE
UsetheTONEswitchtoEQthesignal.Fourchoicesareavailable:
1.BASSandHIGHenhanced.
2.HIGHenhanced.
3.BASSenhanced.
4.FLATresponse.
20. BATTERYCOVER
Slidingdownthelowerpartofthe
bodypackyoucanaccessthebatterycompartment.
21. POWERINDICATOR
ThisorangeLEDlightswhenthereceiveristurnedon.
22. BATTERYLOW
ThisredLEDlightswhenthebatteriesareexhausted:replacethebatteriesassoonaspossible.
