INTRODUCTION
ThankyouforchoosingthisPROELproductandforyourtrustinourbrand,synonymousofprofessionalism,
accuracy, high quality andreliability. All our productsareCEapprovedanddesignedfor continuoususein
professionalsystems.
DESCRIPTION
The RM3000TR is a UHF PLL controlled Wireless Inear Monitoring System providing a reliable and high
qualitysignaltransmission.
RM3000TRfeatures2units:RM3000transmitterandRM3000Rbodypackreceiver.Thesystemisequipped
asfollow:
RM3000TR: RM3000+RM3000R+EB10earphones+AC/DCadaptor+carryingcase
RM3000R: RM3000R+EB10earphones(optionalsecondreceiver)
EB10:  optionalspareearphones
8 channel frequencies are available, allowing the possibility to use the apparatus with other wireless
equipment.
RM3000TRTRANSMITTER
SeeFIG.1atpage15:
1. ANTENNA
Thisisthetransmittingantenna.Useonlytheantennasuppliedwiththesystem,screwitinandraiseit
upduringtheuse.Inordertoobtainanoptimalreception,placethetransmitterawayfromothermetal
andnomorethan50mt.awayfromthereceiver.
2. 1215VDC
SocketfortheAC/DCadaptorconnection:useonlytheadaptorsuppliedwiththesystem.
3. RFPOWER
Thisselectorsetstheradiofrequencycarrieroutputpower.Threelevelsareavailable:
LasLowforanRFpower<10mW
MasMediumforanRFpower<50mW
HasHighforanRFpower<100mW
NOTE:forallEuropeancountriesonlyLsettingcanbeused.
4. LINPUT(comboXLRJACKinputBALANCED)
Leftchannelinput:thisisafemalecomboconnectorthatacceptsaXLRoraJACKplug
fromalmostany
typeofequipmentwithabalancedorunbalancedoutputs.TheXLRinputiswiredasfollows:
Pin1=shieldorground
Pin2=+positiveor"hot"
Pin3=negativeor"cold"
TheJACKinputiswiredasfollows:
Tip=+
positiveor"hot"
Ring=negativeor"cold"
Sleeve=shieldorground
Whenconnectinganunbalancedsignal,theconnectormustbewiredasfollows:
Pin2/Tip=+positiveor"hot"
Pin13/Sleeve=shieldorground
5. RINPUT(comboXLRJACKinput
BALANCED)
SameasabovefortheRightchannel.
6. LOUTPUT(XLRoutputBALANCED)
ThisconnectorprovidesabalancedlinelevelsignalfromtheLINPUT.Connectthistotheinputof
anotheraudioequipmentoranotherRM3000transmitter.
