PROEL SW115A - Diagrams and Dimensions

15
ENG ITA
DIAGRAMS AND DIMENSIONS
DIAGRAMMI E DIMENSIONI
RISPOSTA IN FREQUENZAFREQUENCY RESPONSE
SW115A
____
100Hz /
_ _ _
160Hz
SW115P
0
dB
40 100 1K 10K 20K
Hz
+10
-20
-30
-10
0
dB
40 100 1K 10K 20K
Hz
+10
-20
-30
-10
DIMENSIONS DIMENSIONI
55 cm (21.7 inch)
43 cm (16.9 inch)
60 cm (23.6 inch)
68 cm (26.8 inch)
ENG - stand mounting pole
ITA - angia per supporto
