PART LIST—Model No. 831.295062 R0105A
Key No. Qty. Description Key No. Qty. Description
1 1 Left Foot Rail
2 12 Foot Rail Screw
3 2 Isolator Bolt (Top)
4 2 Isolator Decal
5 2 Isolator Top Cap
6 2 Front Isolator
7 2 Isolator
8 2 Isolator Bottom Cap
9 2 Isolator Bracket Cover
10 2 Isolator Bracket
11 4 Isolator Bracket Bolt
12 2 Isolator Bolt
13 1 Walking Platform
14 2 Belt Guide
15 4 Belt Guide Screw
16 2 Walking Platform Screw (Rear)
17 2 Frame Pivot Bolt
18 1 Front Roller/Pulley
19 1 Magnet
20 8 Pivot Nut
21 2 Pivot Bushing
22 1 Reed Switch
23 1 Reed Switch Screw
24 1 Reed Switch Clip
25 1 Motor Tension Bolt
26 1 Motor Tension Washer
27 1 Ground Wire
28 1 Motor Pulley
29 1 Motor Star Washer
30 1 Motor Tension Nut
31 1 Drive Motor
32 1 Right Bottom Handgrip
33
1
Lift Frame
34
1
Right Handrail
35 2 Walking Platform Nut
36
1 Motor Pivot Pin
37
1
Incline Motor
38 2 Incline Motor Bolt
39 6 1/4” Washer
40
4
1” Tek Screw
41 1 Front Roller Adj. Bolt
42 2 Walking Platform Screw (Front)
43 1 Left Bottom Handgrip
44
5
Hood Screw
45 2 Star Washer
46 2 Latch Screw
47
1
Reset/Off Circuit Breaker
48 1 Controller
49 1 Power Cord
50 1 Power Cord Grommet
51 2 Static Decal
52 10 3/4” Tek Screw
53 3 Belly Pan Clip
54 1 Belly Pan
55 1 Releasable Tie
56 1 Photo Switch Wire
57 1 Tie Holder Clamp
58 1 Cable Tie
59 1 Frame
60 1 Right Rear Foot
61 1 Motor Bracket
62 2 Rear Roller Adj, Bolt
63 1 Rear Roller
64 1 Allen Wrench
65 1 5/32” Allen Wrench
66 1 Left Rear Foot
67 1 Right Foot Rail
68 1 Walking Belt
69 1 Warning Decal
70 1 Filter Wire
71 1 Pulse Bar
72 1 Cotter Pin
73 1 Photo Switch Star Washer
74 1 Wire Harness
75 1 Right Top Endcap
76 4 Upright Bolt
77 4 Internal Star Washer
78 2 Front Isolator Screw
79 2 Small Upright Endcap
80 4 Extension Leg Bolt
81 1 Left Top Endcap
82 1 Latch Assembly
83
1
Controller Wire
84
1
Leveling Foot
85 1 Shock
86
1 Hood Cover
87
1
Hood Decal
88 5 Hood Cover Screw
89* 2 Extension Leg Assembly
90
2
Wheel Bolt
91 2 Warning Decal
92 2 Extension Leg
93 1 Console Back
94
2
Wheel
95 2 Controller Screw
96 1 Access Door
97
1
Upright Base
98 1 Photo Switch
99 4 Base Pad
100 2 Upright Base Endcap
26
To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual.
