PART IDENTIFICATION CHART
M10 Split
Washer (38)
M10 Nylon
Locknut (32)
M4 x 19mm
Screw (45)
M10 x 35mm Screw (34)
M10 x 20mm
Patch Screw (28)
M10 x 62mm Patch Screw (37)
M10 x 114mm Bolt (33)
M10 x 55mm Patch Screw (20)
M4 x 16mm
Patch Screw (26)
M10 x 68mm Bolt (44)
6
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.
To Next Page
