Part List—Model No. PFSY74490
R0401A
Key No. Qty. Description Key No. Qty. Description
1 1 Butterfly Upright
2 1 Press Upright
3 1 Butterfly Front Leg
4 1 Butterfly Base
5 1 Weight Base
6 1 Press Base
7 1 Press Seat Frame
8 1 Press Frame
9 1 Press Top Frame
10 1 Left Butterfly Arm
11 1 Right Butterfly Arm
12 1 Butterfly Backrest
13 2 Seat
14 1 Butterfly Seat Frame
15 4 Weight Guide
16 2 Top Weight
17 1 Short Weight Tube
18 2 Weight Tube Bumper
19 2 Weight Pin
20 1 Press Front Leg
21 18 Weight
22 1 Lock Pin
23 4 Pulley Plate
24 23 3 1/2” Pulley
25 19 Cable Trap
26 2 Small Support Plate
27 2 “V”-Pulley
28 21 2” Square Inner Cap
29 2 Butterfly Foam Pad
30 4 Foam Pad
31 4 Retainer Ring
32 2 Large Cable Trap
33 1 Butterfly Top Frame
34 2 Right Shroud
35 3 1 1/4” Square Inner Cap
36 6 5/16” Washer
37 2 Butterfly Arm Bushing
38 2 1” Round Outer Cap
39 4 Plastic Grip
40 1 Bumper
41 1 Leg Lever
42 2 Pad Tube
43 4 3/4” Round Inner Cap
44 1 Row Bar
45 1 1/4” x 2 1/2” Carriage Bolt
46 7 3/8” x 2 3/4” Bolt
47 2 Pulley Covers
48 21 3/8” Flat Washer
49 8 1/4” x 3/4” Bolt
50 28 3/8” Nylon Locknut
51 4 Weight Bumper
52 1 3/8” x 9” Bolt
53 2 3/8” x 2 1/2” Bolt
54 9 3/8” x 2” Bolt
55 1 Press Plate
56 3 3/8” x 3 1/2” Bolt
57 2 3/8” x 1 3/4” Bolt
58 1 Nylon Strap
59 11 3/8” x 3 3/4” Bolt
60 2 5/16” x 1 3/4” Bolt
61 1 Lat Bar
62 1 3/8” x 3 1/4” Bolt
63 15 3/8” Nylon Jam Nut
64 32 5/16” Nylon Locknut
65 3 Seat Plate
66 1 Weight Top Frame
67 1 Chain
68 5 1/4” Nylon Locknut
69 4 Cable Clip
70 2 Backrest Adjustment Frame
71 10 1/4” Flat Washer
72 1 High Cable
73 1 Butterfly Cable
74 1 Ab Cable
75 1 Low Cable
76 2 1” Inner Cap
77 2 Press Arm
78 3 Adjustment Knob
79 1 1/4” x 2 1/2” Bolt
80 1 1” Tap Screw
81 1 Ab Strap
82 4 1/4” x 1 1/2” Bolt
83 6 1” x 2” Inner Cap
84 2 3/8” x 1” Bolt
85 1 3/8” x 3 3/4” Carriage Bolt
86 2 Small Grip
87 2 Press Grip
88 2 Butterfly Grip
89 22 5/16” x 2 3/4” Bolt
90 1 Seat Adjustment Frame
91 1 Curl Pad
92 8 5/16” x 2 1/2” Carriage Bolt
93 1 Workout Decal
94 6 Support Plate
95 8 1/4” x 5/8” Screw
96 1 Long Weight Tube
97 2 “U” Bracket
98 1 2” x 3” Inner Cap
99 1 Press Backrest
100 2 Plastic Bushing
101 2 1/4” x 1 1/2” Carriage Bolt
102 2 4 1/2” Pulley
103 1 Angle Spacer
104 1 3/8” x 4” Carriage Bolt
105 1 1/2” x 3 1/2” Bolt
106 1 1/2” Nylon Jam Nut
107 1 Curl Post
108 1 3/8” x 5” Bolt
109 2 Left Shroud
# 1 User’s Manual
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice.
