Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice.
1 1 Top Frame
2 1 Butterfly Upright
3 1 Press Upright
4 1 Press Base
5 1 Stabilizer
6 1 Leg Lever Bumper
7 1 #8 x 1Ó Black Screw
8 1 Butterfly Base
9 1 Locking Knob
10 1 Ankle Strap
11 1 Butterfly Seat Frame
12 1 Press Frame
13 2 Seat
14 4 Plastic Sleeve
15 1 Butterfly Backrest Frame
16 1 Top Weight
17 10 1/4Ó x 3/4Ó Screw
18 9 3/8Ó x 2 3/4Ó Bolt
19 2 Weight Bumper
20 2 3/8Ó x 2 3/4Ó Carriage Bolt
21 1 Nylon Jamnut
22 10 5/16Ó x 2 1/2Ó Carriage Bolt
23 2 Weight Guide
24 16 2Ó Square Inner Cap
25 5 5/16Ó Nylon Jamnut
26 14 Weight
27 1 Support Bracket
28 2 Pad Tube
29 1 Leg Lever
30 4 Foam Roller
31 4 Pulley Plate
32 2 5/8Ó x 1/2Ó Bushing
33 4 Handgrip
34 4 3/4Ó Round Inner Cap
35 13 3 1/2Ó Pulley
36 1 Press Seat Frame
37 1 Press Seat Upright
38 1 Press Backrest Frame
39 1 Weight Pin
40 1 1/2Ó Plain Nut
41 2 Backrest
42 2 3/8Ó x 5Ó Bolt
43 1 1Ó x 2Ó Inner Cap
44 10 Cable Trap
45 3 5/16Ó x 2 1/2Ó Bolt
46 1 Right Press Arm
47 1 Left Press Arm
48 3 5/16Ó x 1Ó Bolt
49 2 1/4Ó x 1 3/4Ó Screw
50 18 3/8Ó Nylon Locknut
51 1 1/2Ó Nylon Locknut
52 1 Support Plate
53 5 5/16Ó Flat Washer
54 1 3/8Ó x 3 1/2Ó Bolt
55 4 3/8Ó Flat Washer
56 1 Right Shroud
57 1 Cable Frame
58 2 Foam Handle
59 1 1/2Ó x 9 1/2Ó Bolt
60 4 5/16Ó x 2 3/4Ó Bolt
61 1 Lat Bar
62 6 3/8Ó x 2Ó Bolt
63 2 Weld Cover
64 1 Weight Tube Bumper
65 1 3/8Ó x 4 3/4Ó Bolt
66 1 Weight Cover
67 1 Chain, 16Ó
68 19 5/16Ó Nylon Locknut
69 3 Cable Clip
70 1 Row Bar
71 2 1/4Ó Flat Washer
72 1 Low Cable
73 1 High Cable
74 1 3/8Ó x 2 1/2Ó Bolt
75 2 3/4Ó Dome Cap
76 28 Round Weight Insert
77 1 Weight Tube
78 5 3/8Ó Nylon Jamnut
79 2 ÒVÓ-Pulley
80 1 Right Butterfly Arm
81 1 Left Butterfly Arm
82 2 Butterfly Foam Pad
83 1 Plastic Spacer
84 2 Long Cable Trap
85 2 3/8Ó x 2 1/4Ó Bolt
86 2 3/4Ó Retaining Ring
87 1 Low Pulley
88 2 1Ó Round Inner Cap
89 1 5/16Ó x 6 1/2Ó Bolt
90 1 3/8Ó x 1 1/2Ó Buttonhead Screw
91 4 #10 x 3/4Ó Black Screw
92 4 #10 Flat Washer
93 4 #10 Plain Nut
94 4 #10 Lock Washer
95 4 #8 x 3/4Ó Tek Screw
96 1 Left Shroud
97 1 Butterfly Cable
98 1 Press Arm Locking Pin
99 2 Adjustment Knob
100 1 1 1/2Ó Flat Washer
101 1 Long Adjustment Knob
# 1 UserÕs Manual
Part List - Model No. PFSY92080
R1198A
Key No. Qty. Description Key No. Qty. Description
