18
Adjusting the Tension Control Knob
To increase the tension, turn the Tension Control Knob (62) in a clockwise direction.
To decrease the tension, turn the Tension Control Knob (62) in a counterclockwise direction.
Adjusting the Seat Height
Removed the Adjustment Knob (55) by turning it in a counterclockwise direction until the Seat
Post (3) can be slid up or down freely. When you find a suitable position for the Seat Post (3)
reinsert the Adjustment Knob (55) and lock the seat in place by tightening the Adjustment Knob
(55) in a clockwise direction.
NOTE: When adjusting the height of the seat post, make sure the MAX line stamped on the
right side of the seat post does not pass the plastic bushing.
Tension Control Knob (62)
