1. Front/Rear Stabilizers and Adjustable Levelers Installation:
Align the holes of the Front Stabilizer (54) to the bracket located at the front end of the Mainframe
(59). Make sure the arrow sticker on the Front Stabilizer (54) is pointing up so that the Transport
Wheels (93) are positioned toward the front and parallel to the floor. Insert two Bolts (52) through
the Front Stabilizer (54) and secure with two Curve Washers (55) and two Cap Nuts (56). Using
the Open-Ended Flat Wrench, tighten the Cap Nuts (56) until they are secure.
Align and attach the Rear Stabilizer (62) to the bracket located at the bottom of the back end of
Mainframe (59) with two Bolts (52). Secure the two Bolts (52) with two Curve Washers (55) and
two Cap Nuts (56). Using the Open-Ended Flat Wrench, tighten the Cap Nuts (56) until they are
secure.
Hardware:
Tools:
Open-Ended Flat Wrench
(52) Bolt
4PCS
(55) Curve Washer
4PCS
(56) Cap Nut
4PCS
10
ASSEMBLY
