ProGear LCD-M5 - Outer Shell Size and Material

4
OUTER SHELL SIZE AND MATERIAL
I. OUTER SHELL SIZE AND MATERIAL
Outer shell material is ABS, Liquid crystal transparent window material is high hardness acrylic.
Transfer Ring Selection.
FRONT VIEW
SWITCH FRONT
VIEW
SWITCH SIDE
VIEW
56.4mm
86mm
18.15mm
48mm
48mm
43.85mm
22.2mm
93.4mm
6.4mm
31.8mm
22.2mm
SIDE VIEW
+
31.8mm stent is available
22.2mm, Ø25.4mm,
28.6mm
