Project Source F201E514CP - Page 6

6
ASSEMBLY INSTRUCTIONS
4. Attach vertical shower pipe to the top of the middle
elbow of valve body (D).
4
1
4
2
4-1
all
5. Attach vertical tub pipe to the bottom of the middle
elbow of valve body (D).
Note: Recommend 8 in. minimum distance to spout.
For shower only installation attach plug (H) to the
bottom of the middle elbow of valve body (D) using
thread seal tape.
6. Install stub-out pipe (not included) for spout (G).
Use proper length stub-out pipe so pipe threads will
extend 3-3/4 to 4 inches beyond finished wall.
1
5
1
6
5
6
3
2
5-1
5-2
2
6-1
all
all
D
3-3/4 to 4 in.
H
