4
SPECIFICATIONS
P/No. AC150 AC250B AC400 AC600 AC800 AC1000 AC1500 AC600-24
Type: AUTOMATIC AUTOMATIC AUTOMATIC AUTOMATIC AUTOMATIC AUTOMATIC AUTOMATIC AUTOMATIC
Input: 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz 240VAC 50Hz
Input power: 0.09A (17W) 0.2A (28W) 0.23A (53W) 0.37A (70W) 0.43A (91W) 0.5A (108W) 0.83A (161W) 0.6A (116W)
Output Voltage: (Nominal) 12VDC 12VDC 6 VDC/12VDC 12VDC 12VDC 12VDC 12VDC 24VDC
Output Current: 900mA@12V 1600mA@12V 2700mA 4300mA@12V 5400mA@12V 6200mA@12V 10000mA@12V 3500mA@24V
(Continuous) @6 or 12V
Engine Start: N/A N/A N/A N/A 3 Cycles: N/A N/A N/A
5min ‘ON’
20min ‘OFF’
Suitable for Charging 12V Battery 12V Battery 6 or 12V Battery 12V Battery 12V Battery 12V Battery 12V Battery 2 x 12V
in series (24V)
Battery Range: (CCA) 100-350* 200-650* 250-550 250-650 300-700 300-800 450-1000 400-900*
(MCA) 150-400* 250-700* 250-600 300-700 375-800 375-900 600-1200 450-1000*
(Ah) 7-24 16-40 20-70 25-80 35-100 50-100 65-150 35-70
Minimum Start Voltage: 5V 5V 3V 3V 3V 3V 3V 15V
Charge Control: (Cut out) 14.2V 14.2V 7.1/14.2V 14.2V 14.2V 14.2V 14.2V 28.4V
(Cut in) 13.4V 13.4V 6.7/13.4V 13.4V 13.4V 13.4V 13.4V 26.8V
Size: 65x85x95mm 123x43x120mm 150x140x85mm 150x140x85mm 190x220x120mm 190x220x120mm 190x220x120mm 190x220x120mm
Weight: 0.75Kg 1.3Kg 1.5Kg 1.9Kg 2.5Kg 2.6Kg 3.4Kg 2.6Kg
*Only suitable for maintaining larger size batteries.
