LED CHARGE INDICATORS
These battery chargers include coloured LEDs that illuminate various signals to indicate
different stages of charging.
LED Signals: PC400 & PC800
LED LED SIGNAL & STAGES OF CHARGING
Rejuvenation Soft Start Bulk Charge Absorption Equalisation Analysis Float
Bulk Flashing Solid On Solid On Solid On
(Blue)
– – – –––––– –––––– ––––––
Full Flashing Flashing Solid On
(Green)
– – – – – – ––––––
Rejuvenation Flashing Flashing
(Amber)
– – – – – –
Fault (Red) Fault (See Faults & Errors, page 12)
LED Signals: PC1600 & PC2100
LED LED SIGNAL & STAGES OF CHARGING
Rejuvenation Soft Start Bulk Charge Absorption Equalisation Analysis Float
Bulk Flashing Solid On
(Blue)
– – – ––––––
Absorbtion Solid On Solid On
(Blue)
–––––– ––––––
Full Flashing Solid On
(Green)
– – – ––––––
Rejuvenation Flashing Flashing
(Amber)
– – – – – –
Fault (Red) Fault (See Faults & Errors, page 12)
