SPECIFICATIONS

P/No. PC400 PC800 PC1600 PC2100

Type 6 stage 6 stage 6 stage 6 stage

Input (nominal) 240VAC, 50Hz 240VAC, 50Hz 240VAC, 50Hz 240VAC, 50Hz

Input Power 132W 240W 432W 600W

Output Voltage 12V 12V 12V 12V

Output Current 1, 2, 4A 2, 4, 8A 2, 4, 8, 16A 2, 6, 12, 21A

Minimum Start Voltage 3.0V 3.0V 3.0V 3.0V

Back Drain 1mA 1mA 1mA 1mA

CHARGE CONTROL

Rejuvenation High frequency High frequency High frequency High frequency

charge for 24 hours charge for 24 hours charge for 24 hours charge for 24 hours

Soft Start Half the rated set Half the rated set Half the rated set Half the rated set

current up to 10.5V current up to 10.5V current up to 10.5V current up to 10.5V

Bulk Set current up to: Set current up to: Set current up to: Set current up to:

14.4V (NORMAL) 14.4V (NORMAL) 14.4V (NORMAL) 14.4V (NORMAL)

14.7V (CALCIUM) 14.7V (CALCIUM) 14.7V (CALCIUM) 14.7V (CALCIUM)

Absorption Constant voltage 14.4V (NORMAL), 14.7V (CALCIUM) until current drops to the following set points:

1 Amp setting: 0.15A 2 Amp setting: 0.3A 2 Amp setting: 0.3A 2 Amp setting: 0.3A

2 Amp setting: 0.3A 4 Amp setting: 0.6A 4 Amp setting: 0.6A 6 Amp setting: 0.9A

4 Amp setting: 0.6A 8 Amp setting: 1.2A 8 Amp setting: 1.2A 12 Amp setting: 1.8A

16 Amp setting: 2.5A 21 Amp setting: 3.15A

Equalization Constant current Constant current Constant current Constant current

(Calcium mode only) 2.0A up to 16V 2.0A up to 16V 2.0A up to 16V 2.0A up to 16V

then hold for 30 min then hold for 30min then hold for 30 min then hold for 30 min

or 12 hour timeout or 12 hour timeout or 12 hour timeout or 12 hour timeout

Analysis Stops charging for 5 minutes, tests if battery is above 12.5V

Float 13.7V 13.7V 13.7V 13.7V

BATTERY RANGE

Deep Cycle 7–80Ah 14–160Ah 14–320Ah 14–420Ah

Automotive 40-480CCA 80-1000CCA 80-1900CCA 80-2500CCA

Marine 55-650MCA 110-1300MCA 110-2700MCA 110-3500MCA

Types of Batteries Most types of batteries including GEL, AGM, WET CELL and CALCIUM

Size (mm) 167 x 104 x 66 216 x 118 x 66 229 x 137 x 86 229 x 137 x 86

Weight 0.85 kg 1.0 kg 1.5 kg 1.5 kg

Projecta PC400 User Manual
