Proline PLFI520 - 2 Diagrams; Wall Hood

2 | PROLINE RANGE HOODS
Wall or Island Hood
A - HOOD directs heat and smoke into the hood’s internal blower system. The
blower forces heat and smoke from cooking into the chimney.
B - CHIMNEY vents air from cooking to the outside of the home.
C - CONTROL PANEL - controls the hood’s various features.
D - FILTER(S) - prevent grease and grime from getting into the blower(s). The
number and type of filters depends on the model.
E - LIGHTS - 20 Watt halogen lights or LED Lights. The number and type of
lights depends on the model.
c
a
b
d
E
