Proline SDW800PW/S User Manual

For getting the best performance from your dishwasher,please read all operating instructions before
using it for the first time.
5
Rinse Aid Warning Light : Comes on when the
rinse aid dispenser needs to be refilled .
2
3
4
ON/OFF Button: To turn on/off the power.
Washing Program Selector : Turn the knob to
select wash cycles .
3
Salt Warning Light : Comes on when the water softener
needs to be refilled with salt.
Power Light : Comes on when the ON/OFF Button
is in the ON position.
2
3
4
5
11
12
Back View
13
Main Filter
5
Detergent Dispenser
6
Cup Shelf
7
Silverware Basket
8
Coarse Filter
9
Rinse Aid Dispenser
10
Inlet pipe connector
12
Drain pipe connector
11
Lower Basket
3
Spray Arms
2
Upper Basket
1
Water softener
4
13
Tray assembly
Front view
1
2
3
4
5
6
7
8
9
10
6
Start / Reset Button : Press this button to start
or pause the dishwasher .
6
Start / Reset
