Prolitec GENIE User Manual

Genie 18Chapter 5 OPERATING INSTRUCTIONS
about ten seconds.
6. The ve buttons will light in sequence from left to right.
7. Remove the SD card; the display will show the currently loaded rmware version and the pump
will run for one second.
8. Press : to turn on the power.
9. Be sure that the power is on and the appliance is in Run Program mode prior to closing and
locking the door.
Programming the Appliance from an SD card
1. Copy schedule.txt to a FAT32 formatted SD card.
2. Insert the SD card, with the label side down.
3. Press the reset button, and the ve buttons will light in sequence from left to right.
4. The : and E buttons will light alternately.
5. Press and hold : for one second, and the display will show LOAD for about ten seconds.
6. The ve buttons will light in sequence from left to right.
7. Remove the SD card; the display will show the currently loaded rmware version and the pump
will run for one second.
8. Press : to turn on the power.
9. Press I to cycle through the modes to the Run Program mode.
10. Press L to view the start time for the rst program.
11. Press L again to view the stop time for the rst program.
12. Press E or F to view the second and third programs.
13. Be sure the power is on and the appliance is in Run Program mode prior to closing and locking
the door.
Copying programs to an SD card
1. Insert a FAT32 formatted SD card, with the label side down.
2. Press the reset button, and the ve buttons will light in sequence
from left to right.
3. The : and E buttons will light alternately.
5

Prolitec GENIE Specifications

Power

input voltage	100 – 240VAC
input current	0.6A max
output voltage	15VDC
output current	1.2 A
battery type	Lithium 3V, #CR2032

Operating Environment

working temperature	0˚ to 40˚ C
working humidity	85% or less

Capacity

liquid capacity	500 mL cartridges
service area	Up to 15, 000 cu. ft. (425 m[3])

Weight and Dimensions

dimensions	11” x 7.5” x 3” (27.9 cm x 19.1 cm x 7.6 cm)
weight	5.2 lbs (2.4 kg)
