Advanced Test Products Europe RG5410A-E
- 9 -
OPTIONAL RECOVERY / TANK PRE OR SUB
COOLING FOR FIXED HOSE SET UP
SYSTEM
BEING
SERVICED
LIQUID
VAPOR
VAPOR
LIQUID
MANIFOLD GAUGE SET
INPUT
OUTPUT
A scale must be used
to avoid overfilling the
storage tank.
Normal recovery:
Tank Vapor valve is closed.
Tank pre or sub cooling:
Tank Vapor valve is open and both Manifold Gauge Set valves are closed. Follow
above procedure.
