Promise Technology Smartstor NS4600 Quick Start Guide

Task 8: Setting up a Network Drives on other PCs
27
5. Optional. To join a NIS Domain, click the UNIX/Linux tab (A), then click the
Yes button beside Services. (B)
Note: If you join an NIS Domain, you automatically disable your AD Domain
settings.
6. Enter the Domain name into the field provided. (C)
See your Network Administrator for help with this information.
7. Click the OK button to save your settings. (D)
The setting runs automatically.
Setting up File Sharing
File access from UNIX and Linux PCs is controlled by specifying the IP address
of each PC that can access a given folder.
You must designate the IP addresses for each folder individually. You can have
up to 256 IP addresses for all of your folders.
To set up UNIX/Linux file sharing:
1. Click the Administration topic and choose the File & Print icon to expand
the Tree. (A)
2. Click the Sharing Setup icon (B), then click the UNIX/Linux Sharing tab.
(C)
3. Choose a volume from the Volume dropdown menu. (D)

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
