Promise Technology Smartstor NS4600

Task 1: Package Contents
5
Figure 3. SmartStor 4 Bay Front View
Figure 4. SmartStor 4 Bay Rear View
Warning
Please note that the keyhole of the upper and lower side, to avoid
the machine damage or can not be used.
Disk Drive
Drive Carrier
Disk Activity
LED
Ethernet
Activity LED
One Touch
Backup Button
Disk Status
LED
Note: This SmartStor is shown without the front door.
System Status LED
Keyhole
Power
Connection
USB
Connections
RJ45 Network
Connection
Disk Drive
Cooling Fan
Power
Button
eSATA
Connection
