Promise Technology Smartstor NS4600

SmartStor NAS Quick Start Guide
4
Figure 1. SmartStor 2 Bay NAS Front View
Figure 2. SmartStor 2 Bay NAS Rear View
Disk Drive
Drive Carrier
Disk Activity LED
Ethernet Activity
LED
Disk Status
LED
Note: This SmartStor is shown without the front door.
System Status LED
Power Button
Power Connection
USB Connections
RJ45 Network Connection
Disk Drive
Cooling Fan
