PROPOINT 8880429 - Parts List

V1.0 1,500 LB 120V AC ELECTRIC WINCH 8880429
Visit www.princessauto.com for more information 17
PARTS LIST
#
DESCRIPTION
QTY
1
Clutch knob
1
2 Socket head cap screw M6 2
3 Cross screw M4 2
4
Side plate
1
5 Sliding bearing 1
6 Mounting frame 1
7 Cross screw M5 2
8 Flange nut M5 2
9 Tension plate 1
10 Cross screw M6 2
11
Screw M6
1
12 Drum 1
13 Tie bar 2
14
Cotter pin
1
15 Clutch shaft 1
16 Sliding bearing 1
17 Spring location plate 1
18 Spring 1
19 Cross screw M4 2
20 Gearbox cover 1
21 Washer 3
22
Spline
1
23 Dish gear 1
24 2
nd
planetary gear assembly 1
25
1
st
planetary gear assembly
1
26 Ring gear 1
27 Motor bracket 1
28 Motor assembly 1
29 Control box assembly 1
30 Power cord 1
31 Hook strap 1
32
Switch
1
33 Steel cable & hook 1
34 Hexagon nut M8 2
35
Spring washer 8
2
36 Mounting channel 1
37 Hawse fairlead 1
38 Flat washer 8 2
39 Socket head cap screw M8 2
40 Bracket screw 2
