ProRunner 300 - ASSEMBLY INSTRUCTIONS; Step 1: Attach Uprights

PRO RUN 300 MOTORIZED TREADMILL
10
ASSEMBLY
STEP 1:
First remove your treadmill from the carton as shown in FIG1.
Next rotate up the Left and Right Uprights (26 and 27) and secure with two 10mm Washers (86), two M10 x 53mm Bolts
(87) and two M10 x 20mm Bolts (88) as shown.
