Location of Controls
Back View
Open/close the turntable cover
1. Lift the cover.
2. Push the arms to backward to release the lock.
3. Close the cover.
2.Pull the arms to front to lock it as the figure on left.
LINE OUT jacks
FM antenna
1.Lift the turntable cover.
7
FM ANT ENNA
DC 9V 1 .3A
DC jack
