M
I
N
O
N
.
O
F
F
MAX
VOLUME
Listening to a Record
Turn the Power ON/OFF-VOLUME knob clockwise until a sound
click was heard to turn on the unit.
Turn the Function selector to
the AUX/PH position.
Open the cover.
If plays the small size 45 rpm record, insert the supplied
adaptor to the center spindle before placing the record.
clip
Unlock the clip to release the tone arm as the figure below.
Transportation screw
"
"
Select the speed.
45 RPM adaptor
Step 1
Step 2
8
Note: This adaptor is for 45 RPM only, for the 33-3/1 and
78 RPM do not need to put this adaptor.
Before use, completely loosen the transportation screw
by turning it clockwise.
Take out the stylus guard (white plastic cover).
To Next Page
